LIQUID OFF TAKE SYSTEM (LOT):
LPG LOT System is advance concept in Multi-cylinder Installation
which offers Strength of Bulk LPG Installation and easy functionality.
LPG LOT System can cater to volumes up to 250 Kg per hour Installation
which overcomes lots of problems and demerits of bulk LPG Installation &
conventional Manifold (VOT) system. LPG LOT System withdraws Liquid LPG up
to 10 Kg/Hr
LOT system is an advance concept in multi cylinder installations which
overcomes lots of demerits of Bulk LPG system & conventional
Manifold (VOT) systems. This system is widely used in commercial
& industrial applications only where high pressure is required &
not for domestic purpose.
LOT system withdraws liquid LPG using LOT valves & is
converted into vapor using a vaporizer. LPG off take per
cylinder can go up to 10kg/hr which is comparatively much
more than the normal Vapor off take cylinder of 0.6 kg/hr.
The system offers the efficiency of Bulk installation and easy
functionality of cylinder manifold system. LOT systems are
compact, safe & highly cost effective as liquid is completely
drawn from the cylinder and there is no residual loss.
Advantages of LOT systems
- Requires less area than bulk installations
- Cheaper than bulk installation
- Optimum utilization of gas
- No residual loss
- Constant pressure is maintained at all time
- No need for statutory approvals for installation of < 1000kg
- Easy availability
- Very convenient to handle
- Zero Maintenance cost
- Less space consumption
- No hot water bathing
- Return on investment 4 years if daily consumption is > 40 cylinders
